Red Hat OpenShift v1.1.3

EDB Postgres Distributed for Kubernetes is a certified operator that can be installed on OpenShift using a web interface.

Ensuring access to the EDB private registry

The OpenShift install uses pull secrets to access the operand and operator images, which are held in a private repository.

Once you have credentials to the private repo, you need to create two pull secrets in the openshift-operators namespace:

• pgd-operator-pull-secret for the EDB Postgres Distributed for Kubernetes operator images
• postgresql-operator-pull-secret for the EDB Postgres for Kubernetes operator images

You can create each secret using the oc create command by replacing <TOKEN> with the repository token for your EDB account, as explained in Get your token.

oc create secret docker-registry pgd-operator-pull-secret \
  -n openshift-operators \
  --docker-server=docker.enterprisedb.com \
  --docker-username=k8s \
  --docker-password="<TOKEN>"

oc create secret docker-registry postgresql-operator-pull-secret \
  -n openshift-operators \
  --docker-server=docker.enterprisedb.com \
  --docker-username=k8s \
  --docker-password="<TOKEN>"

Installing the operator

The EDB Postgres Distributed for Kubernetes operator can be found in the Red Hat OperatorHub directly from your OpenShift dashboard.

• From the hamburger menu, select Operators > OperatorHub.
• In the web console, use the search box to filter the listing. For example, enter EDB or pgd:
• Read the information about the operator and select Install.
• In the Operator Installation page, select:
  • The installation mode. Cluster-wide is currently the only mode.
  • The update channel (currently preview).
  • The approval strategy, following the availability on the marketplace of a new release of the operator, certified by Red Hat:
    • Automatic: OLM upgrades the running operator with the new version.
    • Manual: OpenShift waits for human intervention by requiring an approval in the Installed Operators section.

Cluster-wide installation

With cluster-wide installation, you're asking OpenShift to install the operator in the default openshift-operators namespace and to make it available to all the projects in the cluster. This is the default and normally recommended approach to install EDB Postgres Distributed for Kubernetes.

From the web console, for Installation mode, select All namespaces on the cluster (default).

On installation, the operator is visible in all namespaces. In case there were problems during installation, check the logs in any pods in the openshift-operators project on the Workloads > Pods page as you would with any other OpenShift operator.

Creating a PGD cluster

After the installation by OpenShift, the operator deployment is in the openshift-operators namespace. Notice the cert-manager operator was also installed, as was the EDB Postgres for Kubernetes operator (postgresql-operator-controller-manager).

$ oc get deployments -n openshift-operators
NAME                                            READY   UP-TO-DATE   AVAILABLE   AGE
cert-manager-operator                           1/1     1            1           11m
pgd-operator-controller-manager                 1/1     1            1           11m
postgresql-operator-controller-manager-1-20-0   1/1     1            1           23h
…

After checking that the pgd-operator-controller-manager deployment is READY, you can start creating PGD clusters. The EDB Postgres Distributed for Kubernetes repository contains some useful sample files.

You must deploy your PGD clusters on a dedicated namespace/project. The default namespace is reserved.

First, then, create a new namespace, and deploy a self-signed certificate Issuer in it:

oc create ns my-namespace
oc apply -n my-namespace -f \
  https://raw.githubusercontent.com/EnterpriseDB/edb-postgres-for-kubernetes-charts/main/hack/samples/issuer-selfsigned.yaml

Using PGD in a single OpenShift cluster in a single region

Now you can deploy a PGD cluster, for example a flexible 3-region, which contains two data groups and a witness group. You can find the YAML manifest in the file flexible_3regions.yaml.

oc apply -f flexible_3regions.yaml -n my-namespace

Your PGD groups start to come up:

$ oc get pgdgroups -n my-namespace
NAME       DATA INSTANCES   WITNESS INSTANCES   PHASE                PHASE DETAILS   AGE
region-a   2                1                   PGDGroup - Healthy                   23m
region-b   2                1                   PGDGroup - Healthy                   23m
region-c   0                1                   PGDGroup - Healthy                   23m

Using PGD in multiple OpenShift clusters in multiple regions

To deploy PGD in multiple OpenShift clusters in multiple regions, you must first establish a way for the PGD groups to communicate with each other.

Configuring the connectivity is outside the scope of this documentation. However, once you've established connectivity between the OpenShift clusters, you can deploy PGD groups synced with one another.

Channel

The EDB Postgres Distributed for Kubernetes operator is available in a single OLM channel named stable since v1.0.0. All the releases will be available in this channel.

Dependencies

The EDB Postgres Distributed for Kubernetes operator (PGD4K) on OpenShift has the following dependencies:

• EDB Postgres for Kubernetes operator (PG4K): In release v1.0.1 and later, PGD4K is constrained to use an LTS release of PG4K.
• cert-manager: In release v1.1.1 and later, both cert-manager Operator for Red Hat OpenShift and cert-manager Operator for Community are supported.

For more details about the supported versions for each release, see Supported versions. Be aware that can you install or upgrade the PGD4K operator only when those dependencies are met.
